Specifications For KTA50-G
| Engine Type | In-Line, 6-Cylinder | Manufacturer | (CCEC)Chongqing Cummins Engine Co., Ltd. |
| Rated Speed | 1500RPM | Fuel Filter | Dual spin on paper element fuel filters with standard water separator |
| Displacement | 50 L | Standard cooling system | 104 oF (40 oC) ambient radiator |
| Advertised Horsepower | 1500-1675kva (1200-1340 kW) | Length | 5811 mm |
| Peak Torque | 7865 N•m | Width | 2033 mm |
| Bore and Stroke | 6.25 in x 6.25 in (158.8mm x 158.8 mm) | Height | 2330 mm |
| Aspiration | Turbocharged and Charge Air Cooled | Weight (wet) | 10348 kg |
| Frequency | 50/60Hz | Power standard | ESP,PRP,DCP,COP,LTP,MAX |
| Voltage standard | G1,G2,G3,G4 | Certificate standard | UL,NFPA,ISO,IEC,Mil Std,CE,CSA |
Main Features
QSK19 generator sets are fully integrated power generation systems providing optimum performance, reliability and versatility for Stationary Standby and Prime Power applications.
Cummins heavy-duty engine – Rugged 4-cycle, industrial diesel delivers reliable power, low emissions and fast response to load changes.
Alternator – Several alternator sizes offer selectable motor starting capability with low reactance 2/3 pitch windings, low waveform distortion with non-linear loads and fault clearing short-circuit capability.
Permanent Magnet Generator (PMG) – Offers enhanced motor starting and fault clearing short-circuit capability.
Control system – The PowerCommand® electronic control is standard equipment and provides total genset system integration including automatic remote starting/stopping, precise frequency and voltage regulation, alarm and status message display, AmpSentry™ protection, output metering, auto-shutdown at fault detection and NFPA 110 Level 1 compliance.
Cooling system – Standard integral setmounted radiator system, designed and tested for rated ambient temperatures, simplifies facility design requirements for rejected heat.
Enclosures – Optional weather protective and sound attenuated enclosures are available.
NFPA – The genset accepts full rated load in a single step in accordance with NFPA 110 for Level 1 systems.
Warranty and service – Backed by a comprehensive warranty and worldwide distributor network.
